Reliance Electric - AutoMax AutoMate PLC
The Reliance Electric AutoMax AutoMate PLC line is a now discontinued PLC product line with a large installed base throughout the United States, Canada, Europe, and Asia. This rack structured PLC series has progressed in name from AutoMate to DCS 5000 and finally to AutoMax.
| Manual Name | Manual Number | Part Number | Year |
|---|---|---|---|
| 115V Input Module Instruction Manual | J2-3097 | 61C501 | 1996 |
| 2 In 2 Out 0-10 Volt Analog Rail Module | J-3672-3 | 61C350 | 1993 |
| 2 In 2 Out mA Analog Rail Module Manual | J-3673-3 | 61C351 | 1993 |
| 4 Input 0-10 Volt Analog Rail Module Instruction Manual | J-3688-2 | 61C346 | 1993 |
| 4 Input 4-20 Analog Rail Module | J-3689-2 | 61C345 | 1993 |
| 4 Output 0-10 Volt Analog Rail Module | J-3695-2 | 61C366 | 1993 |
| 57C409 Module Specifications | J-3709 | 57C409 | 1988 |
| After-Market Service Support | HM-2838-1 | ||
| AutoMate 15 IO Rail | J-3018-A | 45C1 | 1984 |
| AutoMate AutoMax Digital IO Rails and Manuals | J-3012-3 | 45C1A
45C3, 45C4, 45C5, 45C7 |
1993 |
| AutoMate AutoMax Dual AC DC Input Module | J-3736-1 | 45C40
45C43, 45C44, , |
1993 |
| AutoMate Interface Module | J2-3053 | 57C417 | 1993 |
| AutoMate Local IO Head Instruction Manual | J-3671-2 | 61C22
61C23, , , |
1992 |
| AutoMate Redundancy Instruction | J-3038PA | 1985 | |
| AutoMate Remote Head | J-3037-1 | 45C37
45C37A, 45C38, 45C38A, 45C38B |
1992 |
| AutoMax 115 VAC High Power Output Module | J-3623-2 | 57C403 | 1993 |
| AutoMax 16 Channel Analog Input Module Instruction | J-3613-1 | 61C613 | 1988 |
| AutoMax 2 Channel Analog Input Module Instruction | J-3637-3 | 57C409 | 1992 |
| AutoMax 2-Axis Servo Module Instruction | J-3642-7 | 57C422B | 2001 |
| AutoMax 4 Channel Analog Ouput Module Instruction | J-3631-1 | 57C410 | 1991 |
| AutoMax 4 Output 4-20 mA Analog Rail Module | J-3694-2 | 61C365 | 1993 |
| AutoMax 5-24 VAC Input Module Instruction | J-3632-2 | 57C419 | 1991 |
| AutoMax 5-24VDC Output Module Instruction | J-3633-2 | 57C420 | 1999 |
| AutoMax 8 Channel Isolated Thermocouple Module Instruction | J-3605-1 | 61C605 | 1990 |
| AutoMax AutoMate Dual DC Output Module | J-3740-1 | 45C63
45C65, 45C68, , |
1993 |
| AutoMax AutoMate Thermocouple Voltage Termination Panel | J-3646-1 | 61C614 | 1988 |
| AutoMax Common Memory Module Instruction | J-3636-2 | 47C413B
57C423, , , |
1992 |
| AutoMax Current Input Module | J2-3002-2 | 61C540A | 1993 |
| AutoMax Distributed Power System Overview | S-3005-3 | 1998 | |
| AutoMax Enhanced Basic Language Instruction Manual | J-3675-6 | 1998 | |
| AutoMax Enhanced Ladder Language Instruction Manual | J2-3094-4 | 1998 | |
| AutoMax Ethernet Network Interface Module | J-3696-2 | 57C440A | 1995 |
| AutoMax Input Module Instruction | J-3622-1 | 57C415 | 1991 |
| AutoMax Isolation Short Haul Modem Manual | J-3692 | 57C382 | 1990 |
| AutoMax Ladder Language Editor | J2-3093-3 | 1998 | |
| AutoMax Ladder Logic Language | J-3677-4 | 1994 | |
| AutoMax Low Power Output Module | J-3624-1 | 57C402 | 1991 |
| AutoMax Network Communication Board for GV3000 and AutoMax | D-2895 | 57C380
57C381, 57C404, 57C445, 47C70 |
|
| AutoMax Network Communication Option Board for use with FlexPak and WebPak | D2-3318-5 | 915FK0101 | 2005 |
| AutoMax Network Communications Option Board | D2-3308-7 | 2AX3000 | 1999 |
| AutoMax Network Interface to FlexPak 3000 | D-2907-2 | 57C380
57C381, 57C404, 915FK0101, |
|
| AutoMax Pocket Reference | J-3669-1 | 1998 | |
| AutoMax Power Supply Module and Racks Manual | J-3670 | 57C491
57C331, 57C332, , |
1990 |
| AutoMax Power Supply Modules and Racks | J2-3008-4 | 57C493
57C494, 57C331, 57C332, 57C334 |
1996 |
| AutoMax Processor Module Instruction Manual | J-3650-6 | 57C430A
57C431, 57C435, , |
1996 |
| AutoMax Programming Executive Version 3.5 | J2-3078 | 57C600
57C602, 57C620, 57C622, 57C650 |
1995 |
| AutoMax Programming Executive Version 3.8 | J2-3106-1 | 57C600
57C602, 57C620, 57C622, 57C650 |
1998 |
| AutoMax Pulsetach Input Module Manual | J-3680-3 | 57C421B | 1996 |
| AutoMax Rack Specifications | J-3734-1 | 57C331
57C332, 57C334, , |
1994 |
| AutoMax Remote IO Communications Modules Instruction | J-3606-4 | 57C328
57C329, 57C330, 57C416, 57C554 |
1996 |
| AutoMax Remote IO Head | J-3781 | 57C330 | 1993 |
| AutoMax Resolver Input Module Instruction | J-3640-1 | 57C411 | 1990 |
| AutoMax Run-Time Programming Executive Version 2.1 | J2-3059 | 57C340 | 1993 |
| AutoMax Run-Time Programming Executive Version 3.3 | J2-3060 | 57C341 | 1993 |
| AutoMax Toledo Scale Interface Module Instruction | J-3644-2 | 57C428 | 1991 |
| Data Highway Plus Interface Module | J2-3067-5 | 57C442 | 2001 |
| DCS 5000 Exectutive Software Loading Instructions | J-3617-3 | 1987 | |
| Distributed Power System SA3000 Drive Configuration and Programming Version 1.2 | S-3042 | 57C653 | 1996 |
| Drive Interface Module | J-3697 | 770.91.10
814.52.10, , , |
1992 |
| Dual DC Output Module | J-3008A | 45C63
45C65, 45C68, , |
1984 |
| Dual Digital Input Modules | J-3002C | 45C40
45C43, 45C44, , |
1986 |
| Installing, Operating, and Maintaining Three-Phase IO General Purpose VS Drives | D2-3166-10 | 2001 | |
| IO Rail Jumper Bar Kit | J-3020 | 45C3 | 1987 |
| Isolated Control AD Module | D-2719 | 57409 | 1987 |
| MaxPak III High Speed Link Module Instruction Manual | J2-3010 | 57C424 | 1991 |
| Network Communications Module Instruction Manual | J2-3001-4 | 57C404 | 2010 |
| Norton Editor Reference Manual | J-3618 | 1988 | |
| Reliance Electric Control Products 2004-2005 Catalog | J-415-11 | 45C1
45C2, 45C3, 45C4, 45C5 |
2004 |
| ReSource AutoMax Executive Software Loading Instructions | J2-3047 | 57C395
57C397, 57C345, 57C346, 57C347 |
1993 |
| ReSource AutoMax Programmin Executive V4.0 and DPS Drive Software Installation | J2-3090 | 57C605
57C606, 57C607, 57C625, 57C626 |
1996 |
| ReSource AutoMax Programming Executive and Distributed Power System Drive Software Installation | J2-3086 | 57C600
57C601, 57C602, 57C620, 57C621 |
1995 |
| RTD Termination Panel Instruction Manual | J-3645-2 | 61C615 | 1991 |
| Software Upgrade for the AutoMax PC Link Interface Module Installation Instructions | J2-3084 | 57C446 | 1995 |
| Universal Drive Controller Module Instruction Module | S-3007-3 | O-57552
O-57652, , , |
1998 |
| Voltage Input Module | J-3699-2 | 61C542A | 1993 |
